UL-109 HDPE Mono/Tape Knitted Shade cloth

UL-109 HDPE Mono/Tape Knitted Shade cloth

The DUNET UL-109 is an HDPE Mono/Tape Knitted Shade cloth designed for ultimate protection against UV rays, offering a maximum 90% Shade Factor. This durable material has a nominal fabric mass of 210 gsm, with a warp tensile strength of 585 N and weft of 931 N. It is supplied in rolls of 3.0m width and 50m length. Typical applications include fencing (privacy screens), agriculture, greenhouses, and public shelters, providing robust UV protection in extreme weather.

Category: Brand:
HDPE Mono/Tape Knitted Shade clothProduct code: UL-109
Description

DUNET Knitted shade cloth provides an ultimate protection against U.V Rays with maximum 90% Shade Factor under extreme weather conditions.

Suitable for fencing (privacy screen), Agriculture, Green House & Shelter at public places.

Specifications
FABRIC PROPERTIES PERFORMANCE
Mass per unit (ASTM D3776)
Nominal fabric mass
210 gsm
Bursting strength (ASTM D6797 – 15):
1086 N
Shade Factor:
90 %
Tensile Strength (ASTM D5034-09)
Warp: 585 N
Weft: 931 N
ROLL SPECIFICATIONS Elongation (ASTM D5034-09)
Warp: 71 %
Weft: 60.2 %
Nominal width: 3.0m
Length: 50m
Tearing Strength (ASTM D2261-13)
Warp: 125 N
Weft: 105 N
Approx. roll weight: 31kg
Approx. roll diameter: 34cm
Available Colours

Beige
