Monofilament Knitted Shade Cloth

This Monofilament Knitted Shade Cloth is an HDPE Monofilament Warp Knitted Fabric designed for various applications. It is available in multiple dimensions, including 2MTR X 50MTR and 3MTR X 100MTR, and offers shade factors ranging from 60% to 90%. Constructed from 500 D Mono Filament yarn, its weight varies from 120 gr/m2 to 230 gr/m2 depending on the shade factor. This versatile cloth is suitable for agriculture, construction, and fencing.

Category: Brand:
HDPE Monofilament Warp Knitted FabricMonofilament Knitted Shade Cloth
Description

Characteristics HDPE Monofilament Warp Knitted Fabric Applications • Agriculture • Construction • Fencing

Specifications
2MTR X 50MTR 2MTR X 100MTR 3MTR X 100MTR 3.66MTR X 100MTR 4MTR X 50MTR
Shade Factor 60% 73% 80% 90% TEST METHOD
Weight 120 gr/m2 150 gr/m2 200 gr/m2 230 gr/m2
Yarn Type Mono Filament 500 D 500 D 500 D 500 D BS3865
Tensile Strength Warp: 49 kg | Weft:69 kg Warp:60 kg | Weft:73 kg Warp:63 kg | Weft:77 kg Warp:70 kg | Weft:84 kg ISO 5082
Tear Strength Warp:6.5 kg | Weft:11.6 kg Warp:8.6 kg | Weft:12.6 kg Warp:10.7 kg | Weft:16.6 kg Warp:12 kg | Weft:18 kg ISO 4674
