GeoDura Pond Liner

GeoDura Pond Liner
GeoDura Pond Liner - Image 2
GeoDura Pond Liner - Image 3
GeoDura Pond Liner - Image 4
GeoDura Pond Liner - Image 5

GeoDura Pond Liner

The GeoDura 16 Pond Liner is a durable solution for water containment, featuring a 16 mil thickness and a base scrim of 8×8 2000D Black. It offers excellent UV resistance, retaining over 90% strength after 2000 hours of exposure. This liner weighs 244 Gr/Sqm (7.4 OZ) and is available in Black or IceBlue. It comes with a 5-year warranty for exposed applications and a 10-year warranty when buried.

Category: Brand:
8×8 2000D Black ScrimGeoDura Pond Liner · Type: GeoDura 16
Key Features
• Thickness 16 Mils (ASTM D-1777)
• Weight 244 Gr/Sqm (7.4 OZ) ± 3%
• UV Resistance >90% Strength Retention After 2000Hrs Exposure
• Warranty 5 Years (Exposed) / 10 Years (Buried)
• Colors Available Black / IceBlue
Specifications
Type GeoDura 16
Base Scrim 8×8 2000D Black
Thickness (ASTM D-1777) 16 Mils
Weight (ASTM D-3776) 244 Gr/Sqm (7.4 OZ) ± 3%
Accelerated UV Weathering ASTM G151 / ASTM G154 >90% Strength Retention After 2000Hrs Exposure @0.77 W/m2/nm Exposure @1.35 W/m2/nm
Grab Tensile Strength (ASTM D-7004) Warp: 240 lbs / Weft: 220 lbs
Tongue Tear Strength (ASTM D-5884) Warp: 81.2 lbs / Weft: 89 lbs
Strip Tear Strength (ASTM D-7803) Warp: 177 lb/in / Weft: 162 lb/in
Mullen Burst Strength (ASTM D-751) 463 psi (3192 Kpa)
Hydro Static Resistance (ASTM D-751) 305 psi (2103 Kpa)
Standard Fabric Width 3.66m (144 Inch)
Standard Roll Length 50m (165ft)
Colors Available Black / IceBlue
Warranty 5 Years (Exposed) / 10 Years (Buried)
