B7195 PVC Coated Panama Fabric

B7195 PVC Coated Panama Fabric

This B7195 PVC Coated Panama Fabric features a high tenacity polyester base cloth with PVC coating on both sides, offering superior durability. Weighing 1100 Gr/Sqm and 205 cm wide, it is UV resistant, flame retardant to BS 5867, and offers anti-mildew/anti-fungus properties. This strong, smooth, and flexible material is temperature resistant from -30°C to +70°C. Ideal for demanding applications like silo covers and equipment covers, it ensures reliable protection.

Category: Brand:
Width: 205 cmPVC Coated Panama Fabric · Polyester Base Cloth · 1100 Gr/Sqm
Features

• UV Resistant

• Flame Retardant As BS 5867 — Part:2:2008

• Anti-mildew; anti-fungus available

• High tenacity polyester yarn ensures superior durability

• Strong, smooth flexible material

Specifications
Base Cloth Polyester (DIN6000)
Construction 30×30/Inch Panama Weave (DIN EN 1049-2)
Yarn (detex) 1000*1000 D (DIN EN ISO 2060)
Type of Coating PVC Coated on both sides
Total Weight 1100 Gr/Sqm (DIN EN ISO 2286-2)
Width 205 cm (DIN EN ISO 2286-1)
Tensile Strength Warp: 4000N/5cm, Weft: 3800N/5cm (DIN 53354)
Tear Strength Warp: 550N/5cm, Weft: 500N/5cm (DIN 53356)
Adhesion Strength 100N/5cm
Temperature Resistant -30°C to +70°C
Flame Retardant BS 5867 : Part 2 : 2007
Applications

• Silo Cover

• Equipment Covers
